Avaya Aura Core Components Support Exam v1.0 (7220X)

Page:    1 / 6
Total 83 questions

How can an inactive SM100 be reset?

  • A. Click the repair button on the Replication page with the affected Avaya Aura® Session Manager (SM) selected.
  • B. Click the 'Reset' button on the Security Module Status page in Avaya Aura® System Manager (SMGR).
  • C. Run the resetSM100 command from RHEL Command Line Interface of Avaya Aura® Session Manager (SM)
  • D. Restart Services on the Avaya Session Border Controller for Enterprise (SBCE).


Answer : C

A customer states they are having voice quality issues when they make calls over a WAN link. You would like see what the Quality of Service is for a call, as the customer makes the call.
Which Avaya Aura® Communication Manager (CM) SAT command will display packet loss and jitter for a call in progress?

  • A. monitor station qos xxxx, where XXXX is the station number
  • B. list monitor qos
  • C. status station qos xxxx, where XXXX is the station number
  • D. list trace station xxxx, where XXXX is the station number.


Answer : D

Which two methods are used to obtain Avaya Aura® Communication Manager (CM) software version information? (Choose two.)

  • A. In CM SMI, navigate to Administration > Server Maintenance > Server > Software Version.
  • B. In Avaya Aura® System Manager (SMGR), navigate to Services > Inventory > Managed Elements.
  • C. In Linux, issue the swversion. command.
  • D. In Linux, issue the software version show.command.
  • E. In CM SAT, issue the display software version. command.


Answer : AC

When viewing Avaya Aura® Communication Manager (CM) trusted certificates, you notice that the installed certificates are marked with either A, C, W, or R.
What do these letters stand for?

  • A. Accepted, Confirmed, Whitelisted and Rejected
  • B. Accumulated, Compressed, Write and Read
  • C. Authentication, Authorization and Accounting Services, Communication Manager, WEB Server and Remote Logging.
  • D. Authentication, Access and Accounting Services, Communication Manager, Web Server and Remote logging.


Answer : C

How can you view the entire contents of the current Avaya [email protected] Communication Manager CM call processing log file?

  • A. by using the CM SAT to enter the list callp log all commands
  • B. by using the Linux cd to /var/log/Avaya and cat ecs.log commands
  • C. by using the Linux cd to /var/log/ecs and ls -l commands to find current <log filename>; cat <log file name>
  • D. by using the CM SAT to enter the display callproc log all command
  • E. by using the Linux cd to /var/log/Avaya and cat callproc.log commands


Answer : C

In which three states can an Avaya Aura® System Manager (SMGR) Alarm exist? (Choose three.)

  • A. Active
  • B. Raised
  • C. Resolved
  • D. Acknowledged
  • E. Cleared


Answer : BDE

A customer reports that several Remote Worker new hires were trying to call co-workers in the office, but noticed their feature buttons were not working. After running a SIP trace, the administrator did not see any PPM Responses coming from Avaya Aura® Session Manager (SM).
After looking at how the call flow is supposed to go, the administrator looked at the SIP communication profile and saw that CM had not been administered as a sequenced application.
If CM had been added to the endpoint's SIP Communication Profile as a Sequenced Application, which step was missing in the call flow?

  • A. PPM is downloaded to the Remote Worker telephone from Avaya Aura® System Manager (SMGR).
  • B. PPM is downloaded to the Remote Worker telephone from Avaya Aura® Session Manager (SM) via Avaya Session Border Controller for Enterprise (SBCE).
  • C. PPM is downloaded to Avaya Aura® Session Manager (SM) from CM.
  • D. PPM is downloaded to the Remote Worker telephone from CM.


Answer : B

What are two purposes of the Shared Bandwidth Management feature introduced in Avaya Aura® R7.l? (Choose two.)

  • A. Protect the quality of existing connections by allowing oversubscription
  • B. Provide more DSP resources to the Remote Workers
  • C. Better determination of bandwidth usage at any location
  • D. Protect the quality of existing connections by preventing oversubscription
  • E. Prevent the use of compressed Codecs during video call


Answer : CD

The client has finished deploying Avaya Aura® Communication Manager (CM) and has signed a service contract with Avaya for technical support.
What should be done by the system administrator in CM to allow Avaya services to login and support the platform?

  • A. It is not necessary to do something. Avaya Services can access by default
  • B. EASGManage -disableEASG
  • C. EASGManage -enableEASG
  • D. EASGTurnOn
  • E. EASGManage -turnonEASG


Answer : C

Reference: https://downloads.avaya.com/css/P8/documents/101038495

A customer calls Avaya Support stating their Session Manager (SM) is down. After some troubleshooting the technician sees SM is in the Deny New Service state and in Restricted license mode.
What does this license mode indicate?

  • A. The license only contains a number of SIP User Agent licenses and is missing the SIP trunking licenses.
  • B. There is a license error but SM continues to function.
  • C. The license 30 day grace period has expired and SM service is being denied
  • D. The license does not contain any SIP User Agent licenses.


Answer : C

You are preparing to enable EASG to provide Avaya Services local and remote access for performing support and system optimization.
What are the two methods to enable EASG during the implementation? (Choose two.)

  • A. During the OVA deployment
  • B. Using the CLI command EASGManage after deployment
  • C. Open a ticket to Avaya services and request to enable it
  • D. Using SMGR web GUI, check the "Enable EASG" check box on the desired component in the Inventory/Manage Elements screen
  • E. Using the SDM after the deployment


Answer : BD

Reference: https://downloads.avaya.com/css/P8/documents/101038495

When comparing two Remote Worker SIP clients, one is an Avaya Communicator soft client and the other is a 96X1SIP hardphone, which statement is true?

  • A. Both Avaya Communicator and 96X1SIP clients register with SM via SBCE and receive their SIP Controller List by PPM download.
  • B. The Avaya Communicator receives its SIP Controller List via 46xxsettings.txt file download, whereas the 96x1 receives its SIP Controller List by PPM download.
  • C. If required, Avaya Communicator and 96X1 clients will automatically upgrade themselves from software stored on the SBCE.
  • D. Avaya Communicator registers with SM via SBCE whereas the 96X1 telephone registers with CM via SBCE.


Answer : B

You are configuring Shared Bandwidth Management for Call Admission Control (CAC) between Communication Manager (CM) and Session Manager (SM).
Which two tasks must you perform to achieve this? (Choose two.)

  • A. Specify the shared bandwidth limit on the Communication Manager (SIP) Entity screen
  • B. Create Network Region Groups (NRG) in Communication Manager
  • C. Create Locations in Session Manager
  • D. Create a Bandwidth Share Group in SM
  • E. Match the Network Region used for the SIP users with the Domain in SM


Answer : AD

Reference: https://downloads.avaya.com/css/P8/documents/101008709

A customer has learned about the benefits of using CAC Sharing and asked you to implement it between the Session Manager (SM) in Main office and
Communication Manager located in a branch location.
What are the steps that you must follow to implement CAC Sharing?

  • A. In Communication Manager: Configure Network Regions and Network Regions Group, Enable Shared Bandwidth Management. In Session Manager: Configure Location, Assign Bandwidth limits to the location, Enable shared Bandwidth Management for Network Region SIP entity.
  • B. In Communication Manager: Configure Network Regions and Network Regions Group, Enable Shared Bandwidth Management. In Session Manager: Configure Location, Assign Bandwidth limits to the Entity Link, Enable shared Bandwidth Management for CM SIP entity.
  • C. In Communication Manager: Configure Network Regions and Network Regions Group, Enable Shared Bandwidth Management. In Session Manager: Configure Location, Assign Bandwidth limits to the location, Enable shared Bandwidth Management for CM SIP entity.
  • D. In Communication Manager: Configure Network regions and Shared Bandwidth Management Groups. In Session Manager: Configure Location, Assign Bandwidth limits to the location, Enable shared Bandwidth Management for CM SIP entity.


Answer : A

Which three statements about media-processing resources (DSPs) are true? (Choose three.)

  • A. Two-party calls originated by SIP stations or trunks, and terminated by H.323 trunks, media gateways, or other vendors' H.323 stations, will typically shuffle if CM is configured to do so.
  • B. Two-party calls originated by H.323 stations, trunks, or media gateways, and terminated by SIP stations or trunks, cannot shuffle.
  • C. SIP-SIP two-party calls will always use SIP Direct Media if Communication Manager (CM) is configured to do so.
  • D. H.323-H.323 two-party calls will always shuffle to establish a direct media path if CM is configured to do so.
  • E. If a direct media path cannot be established between two IP endpoints the call will fail from release 7.0.


Answer : BCE
