Implementing CUCM for TelePresence Video Solutions (PAIUCMTV) v1.0 (642-278)

Page:    1 / 4
Total 58 questions

Which statements best describes Urgent priority operations in relation to call routing in Cisco Unified Communications Manager?

  • A. An Urgent Priority operation is initiated whenever a TelePresence endpoint user presses the # key for immediate dialing
  • B. An urgent Priority operation can be configured on a route pattern to force immediate routing when a first match is detected, even if there are longer route patterns that are also potential matches
  • C. Urgent priority operations cannot be used for VoIP rout patterns; they are only applicable to PSTN route patterns
  • D. An urgent Priority operation is not supported in TelePresence calls

Answer : B

Which two statements regarding Cisco Unified Communications Manager user privileges are correct? (Choose two.)

  • A. A user can be a member of more than one user group
  • B. A role can only tie assigned to one user group
  • C. A role refers to one or more applications
  • D. An application can be referred to by only one role
  • E. A resource Is assigned one privilege per role

Answer : AE

When analyzing digits, Cisco Unified Communications Manager Consider them one by one. If an endpoint was sending digits to Cisco Unified Communications
Manager and the pattern of the seven digits no longer matched a route pattern in the Cisco Unified Communications Manager dial plan, what would occur?

  • A. Cisco Unified Communications Manager would extend the call to the closest matched endpoints
  • B. A fast-busy tone would be set
  • C. Cisco Unified Communications Manager would wait for an interdigit timeout
  • D. The call would be detected to the default voice gateway

Answer : B

Which of the following accurately describes DTMF OOB signaling?

  • A. SIP phones use either RFC 2833 or KPML
  • B. SIP phones cannot use OOB
  • C. SIP trunk, are always sent DTMF In band
  • D. SCCP and SIP phones both use KPML
  • E. SIP trunks use KPML exclusively

Answer : A

Which two of these accurately describe Cisco Unified Communications Manager application users? (Choose two.)

  • A. associated with devices
  • B. cannot use LDAP
  • C. use interactive logins
  • D. not included in user directories
  • E. used to enable user features

Answer : AE

When integrating Cisco Unified Communications Manager in a Cisco TelePresence deployment, which three of the following would require a SIP trunk? (Choose three.)

  • A. Cisco TelePresence codec
  • B. The Cisco Unified IP phone 7975G in the Cisco TelePresence room
  • C. Cisco TelePresence multipoint Switch
  • D. Cisco Unified Videoconferencing 5200 Series MCU
  • E. Cisco TelePresence Recording Servers

Answer : ABC

Which three functions does the Master Agent perform? (Choose three.)

  • A. interfaces with the DRS agent on the Administrator PC
  • B. controls backup and restoration of the system
  • C. communicates with archive devices
  • D. executes backup and restore tasks
  • E. acts as a backup repository
  • F. stores DRS configuration

Answer : BCF

Which three characteristics are used to determine which devices go into a device pool? (Choose three.)

  • A. device type
  • B. class of service
  • C. geographic proximity
  • D. extension mobility CSS
  • E. user hold MOH source
  • F. auto-registration CSS

Answer : CEF

Which two configurations provide the best SIP trunk redundancy with Cisco Unified Communications Manager? (Choose two.)

  • A. Configure all SIP trunks with DNS SRV.
  • B. Configure all SIP trunks with Cisco Unified Border Element
  • C. Configure all SIP trunks to point to a SIP gateway
  • D. Configure SIP trunks to be members of route groups and route lists
  • E. Configure all SIP trunks to allow TCP ports 5060
  • F. Configure all SIP trunks to point to a gatekeeper through SIP to H 323 gateway

Answer : BD

Which two of the following protocols are used between the Cisco TelePresence System and Cisco Catalyst switches? (Choose two.)

  • A. Cisco discovery Protocol
  • B. SCCP
  • C. IEEE 802.1Q
  • D. KEE802.1X
  • E. MGCP
  • F. IEEE 802.3af

Answer : AC

Which of the following operates as a SIP back-to back user agent?

  • A. Cisco TelePresence codec
  • B. Cisco TelePresence Multipoint Switch
  • C. Cisco Unified Cornmunic3tions Manager
  • D. SIP gateway that is used to access the PSTN
  • E. H.323 gateway

Answer : C

ABC Company has four locations total, all connected via an IP WAN. Each location has a Cisco Unified Communications Manager cluster and the headquarters cluster is connected to all other clusters via intercluster trunks. ABC wants to allow up to eight simultaneous calls across the IIP WAN. To call between sites, an employee dials a 2-digit access code plus a 4-digit extension. If more than eight calls are made, or if the IP WAN is not available. Calls should be sent to ABC
Company"™s preferred long-distance carrier. If the trunk to the long-distance carrier is not available, the local provider should be used. The long-distance carrier requires 10 digits to complete a long distance call. The local provider requires 11 digits to complete a long-distance call but only 7 digits local calls. What is the minimum number of route lists required at the headquarters locations?

  • A. 1
  • B. 2
  • C. 3
  • D. 4
  • E. 5
  • F. 6

Answer : C

In considering class of service in Cisco Unified Communications Manager, which three of the following configuration elements can be placed into action? (Choose three.)

  • A. Route pattern
  • B. Translation pattern
  • C. Hunt group
  • D. Director number
  • E. Calling Search Space

Answer : ABE

In reference to translation patterns, which three statements are correct? (Choose three.)

  • A. The translation patterns can be used to change the CSS applied to a call
  • B. The translation patterns can be used to modify the redirecting number
  • C. The translation patterns can be used to modify the calling number
  • D. After matching a translation pattern and performing digit transformations, the call is sent to the original called number
  • E. The translation patterns cannot contain wildcards
  • F. The translation patterns are always considered urgent priority

Answer : ACF

Which three of the following qualify a Cisco Catalyst switch as voice-enabled? (Choose three.)

  • A. allows the configuration of a trunk port
  • B. supports voice and data VLANs on a single access port
  • C. Prioritizes voice traffic with CoS or DSCP marking
  • D. supplies inline power to IP phones
  • E. allows the configuration of a trunk port

Answer : ACD
