What is the default interval at which Cisco devices send Cisco Discovery Protocol advertisements?
Answer : B
Explanation:
Cisco Discovery Protocol is a Layer 2, media-independent, and network-independent protocol that networking applications use to learn about nearby, directly connected devices. Cisco Discovery Protocol is enabled by default. Each device configured for Cisco Discovery Protocol advertises at least one address at which the device can receive messages and sends periodic advertisements (messages) to the well-known multicast address 01:00:0C:CC:CC:CC. Devices discover each other by listening at that address. They also listen to messages to learn when interfaces on other devices are up or go down.
Advertisements contain time-to-live information, which indicates the length of time a receiving device should hold Cisco Discovery Protocol information before discarding it. Advertisements supported and configured in Cisco software are sent, by default, every 60 seconds.
Reference:
http://www.cisco.com/en/US/docs/ios-xml/ios/cdp/configuration/15-mt/nm-cdp-discover.html
Which statement about Cisco Discovery Protocol configuration on a Cisco switch is true?
Answer : A
Explanation:
CDP is enabled on your router by default, which means the Cisco IOS software will receive CDP information. CDP also is enabled on supported interfaces by default. To disable CDP on an interface, use the "no cdp enable interface" configuration command. To disable it globally, use the "no cdp run" command.
Reference:
http://www.cisco.com/en/US/docs/ios/12_2/configfun/command/reference/frf015.html#wp1017573
Which VTP mode is needed to configure an extended VLAN, when a switch is configured to use VTP versions 1 or 2?
Answer : D
Explanation:
VTP version 1 and version 2 support VLANs 1 to 1000 only. Extended-range VLANs are supported only in VTP version 3. If converting from VTP version 3 to VTP version 2, VLANs in the range 1006 to 4094 are removed from VTP control.
Reference:
http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/ios/12.2SX/configuration/guide/vtp.html
What is the size of the VLAN field inside an 802.1q frame?
Answer : B
Explanation:
The VLAN field is a 12-bit field specifying the VLAN to which the frame belongs. The hexadecimal values of 0x000 and 0xFFF are reserved. All other values may be used as VLAN identifiers, allowing up to 4,094 VLANs
Reference:
http://en.wikipedia.org/wiki/IEEE_802.1Q
What is the maximum number of VLANs that can be assigned to an access switchport without a voice VLAN?
Answer : B
Explanation:
A standard (non-voice VLAN port) access switch port can belong to only a single VLAN. If more than one VLAN is needed, the port should be configured as a trunk port.
Refer to the exhibit.
Answer : A
Explanation:
In this case, the port has been configured both as a trunk and as a switchport in data vlan 10. Obviously, a port can not be both, so even though Cisco IOS will accept both, the port will actually be used as a trunk, ignoring the switchport access VLAN 10 command.
Which feature is automatically enabled when a voice VLAN is configured, but not automatically disabled when a voice VLAN is removed?
Answer : A
Explanation:
Voice VLAN Configuration Guidelines
-> You should configure voice VLAN on switch access ports.
The voice VLAN should be present and active on the switch for the IP phone to correctly communicate on the voice VLAN. Use the show vlan privileged EXEC
In which portion of the frame is the 802.1q header found?
Answer : A
Explanation:
Frame format -
Which VLAN range is eligible to be pruned when a network engineer enables VTP pruning on a switch?
Answer : C
Explanation:
VTP pruning should only be enabled on VTP servers, all the clients in the VTP domain will automatically enable VTP pruning. By default, VLANs 2 "" 1001 are pruning eligible, but VLAN 1 can"™t be pruned because it"™s an administrative VLAN. Both VTP versions 1 and 2 supports pruning.
Reference:
http://www.orbit-computer-solutions.com/vtp-pruning/
Which feature must be enabled to eliminate the broadcasting of all unknown traffic to switches that are not participating in the specific VLAN?
Answer : A
Explanation:
VTP ensures that all switches in the VTP domain are aware of all VLANs. However, there are occasions when VTP can create unnecessary traffic. All unknown unicasts and broadcasts in a VLAN are flooded over the entire VLAN. All switches in the network receive all broadcasts, even in situations in which few users are connected in that VLAN. VTP pruning is a feature that you use in order to eliminate or prune this unnecessary traffic.
Reference:
http://www.cisco.com/c/en/us/support/docs/lan-switching/vtp/10558-21.html#vtp_pruning
Refer to the exhibit.
Answer : C
Explanation:
Only VTP servers can add new VLANs to the switched network, so to enable vlan 10 on this switch you will first need to change the VTP mode from client to server. Then, you will need to enable 802.1Q trunking to pass this new VLAN along to the other switches.
Refer to the exhibit.
Answer : C
Explanation:
Since the number of existing VLANs differ on the switches (9 on A and 42 on B) we know that there is a problem with VTP or the trunking interfaces. The VTP domain names do match and they are both VTP servers so there are no issues there. The only viable solution is that there is a DTP issues and so you must instead manually configure the trunk ports between these two switches so that the VLAN information can be sent to each switch.
A network engineer must implement Ethernet links that are capable of transporting frames and IP traffic for different broadcast domains that are mutually isolated.
Consider that this is a multivendor environment.
Which Cisco IOS switching feature can be used to achieve the task?
Answer : C
Explanation:
Here the question asks for transporting "frames and IP traffic for different broadcast domains that are mutually isolated" which is basically a long way of saying
VLANs so trunking is needed to carry VLAN information. There are 2 different methods for trunking, 802.1Q and ISL. Of these, only 802.1Q is supported by multiple vendors since ISL is a Cisco proprietary protocol.
Which statement about using native VLANs to carry untagged frames is true?
Answer : A
Explanation:
Cisco Discovery Protocol (CDP) version 2 passes native VLAN information between Cisco switches. If you have a native VLAN mismatch, you will see CDP error messages on the console output.
Reference:
http://www.ciscopress.com/articles/article.asp?p=29803&seqNum=3
Refer to the exhibit.
Answer : C
Here we see that the native VLAN has been configured as 2013 on one switch, but 1 (the default native VLAN) on the other switch. If you use 802.1Q trunks, you must ensure that you choose a common native VLAN for each port in the trunk. Failure to do this causes Cisco switches to partially shut down the trunk port because having mismatched native VLANs can result in spanning-tree loops. Native VLAN mismatches are detected via spanning tree and Cisco Discovery
Protocol (CDP), not via DTP messages. If spanning tree detects a native VLAN mismatch, spanning tree blocks local native VLAN traffic and the remote switch native VLAN traffic on the trunk; however, the trunk still remains up for other VLANs.
Reference:
http://www.informit.com/library/content.aspx?b=CCNP_Studies_Switching&seqNum=25
