Managing Citrix XenDesktop 7 Solutions Exam v6.5 (1Y0-200)

Page:    1 / 9
Total 124 questions

Scenario: External users are experiencing issues connecting to Internet applications through NetScaler. Clientless Access is disabled.
Which action should a Citrix Administrator take to investigate the cause of this issue?

  • A. View dmesg.boot.
  • B. Open NetScaler Plug-in logging.
  • C. Configure ACL and TCP logging.
  • D. Configure Auditing on the NetScaler.


Answer : B

A Citrix Administrator creates an external network in a XenServer deployment; however, virtual machines connected to the newly created external network CANNOT communicate with other devices on the same subnet as the XenServer host.
The virtual machines are unable to communicate with devices on the same subnet as the
XenServer host because __________ or __________. (Choose the two correct options to complete the sentence.)

  • A. the virtual machines are behind a NAT router
  • B. MAC filtering is enabled on the external network
  • C. the link status for the external NIC is disconnected
  • D. the virtual machines are on a VLAN that is configured incorrectly


Answer : C,D

Scenario: A Citrix Administrator is modifying a vDisk. The administrator finishes making changes to the vDisk and promotes it to production. Now, only one machine is working with the new vDisk.
In which access mode should the administrator put the vDisk so that multiple target devices can boot from this vDisk?

  • A. Test
  • B. Private
  • C. Standard
  • D. Production
  • E. Maintenance


Answer : C

Scenario: Users who connect through the NetScaler are receiving the following error after they log on with their username and password:
Http/1.1 Internal Server Error 29
A Citrix Administrator checks the status of the NetScaler and does NOT find any alerts on the System Log.
Which server could be causing this error?

  • A. Database
  • B. StoreFront
  • C. Citrix Licensing
  • D. Domain Controller


Answer : B

Which file should a Citrix Administrator edit to configure log settings on the StoreFront server?

  • A. web.config
  • B. global.aspx
  • C. logout.aspx
  • D. default.html


Answer : A

Scenario: A Citrix Administrator provisions 50 server OS machines to host applications.
The administrator assigns a delivery group to the machine catalog containing the server
OS machines. When viewing the delivery group in Citrix Studio, the administrator discovers that one of the server OS machines is unregistered.
Which two actions should the administrator take to resolve this issue? (Choose two.)

  • A. Restart the Delivery Controller.
  • B. Ensure that the machine catalog is NOT in maintenance mode.
  • C. Add the appropriate exclusions to the firewall rules on the virtual machine.
  • D. Ensure time synchronization between the Virtual Delivery Agent and the Delivery Controller.


Answer : C,D

A Citrix Administrator plans to use Provisioning Services to provision server OS machines and desktop OS machines that boot from vDisks. Which two components are required in order to provision the machines? (Choose two.)

  • A. Citrix Receiver
  • B. XenServer Tools
  • C. Virtual Delivery Agent
  • D. Target device software


Answer : C,D

Which action should a Citrix Administrator take when using Provisioning Services to provision additional Windows Server 2012 server OS machines in a machine catalog?

  • A. Create a vDisk for the OS.
  • B. Add the OS to the vDisk store.
  • C. Create a site for virtual machines.
  • D. Add the virtual machines to the device collection.


Answer : D

Scenario: A Citrix Administrator implemented a Citrix policy to set up Citrix Profile
Management. After the administrator implemented the policy, users are still being required to set up their applications each time they logon.
What is preventing the existing policy from working?

  • A. The .INI file does NOT exist.
  • B. There are no filters set within the policy.
  • C. The path specified to save the profile is incorrect.
  • D. The users need to be removed from the Citrix profile group.


Answer : C

A user reports that a virtual desktop is taking longer than normal to launch.
Where, in Citrix Director, could a Citrix Administrator find information to address this issue?

  • A. Machine Details
  • B. Activity Manager
  • C. Connection Failures
  • D. Average Logon Duration


Answer : D

A NetScaler has been configured to provide access to external users in a XenDesktop deployment.
Which piece of information should a Citrix Administrator obtain to determine the number of external users that have used NetScaler?

  • A. AAA statistics
  • B. Current AAA Sessions
  • C. Current ICAOnly Sessions
  • D. Authentication success vs. failures


Answer : B

A Citrix Administrator creates a backup schedule that will back up all of the available vDisks.
Which three critical file types must to be added to the backup schedule? (Choose three.)

  • A. BAK
  • B. PVP
  • C. VHD
  • D. LOK
  • E. AVHD


Answer : B,C,E

A Citrix Administrator makes changes to a Windows Firewall, and immediately after, the virtual desktops start to move to an unregistered state.
The virtual desktops are becoming unregistered because they CANNOT __________.
(Choose the correct option to complete the sentence.)

  • A. contact the Delivery Controller
  • B. contact the Provisioning Services server
  • C. contact the Citrix License Server
  • D. resolve the FQDN of the StoreFront server


Answer : A

Scenario: Target devices are failing to boot properly. A Citrix Administrator tries to restart some of the target devices, but the target devices are stalling at the connecting vDisk stage. The administrator also tries to restart the Provisioning Services servers one at the time, but the issue continues. The administrator notices that the Provisioning Services
Streaming Services are starting successfully.
What should the administrator verify next?

  • A. The database is reachable.
  • B. The DHCP server is reachable.
  • C. The write-cache location is reachable.
  • D. The vDisk store locations are reachable.


Answer : D

Scenario: A Citrix Administrator is managing replication in the Provisioning Services environment. The administrator discovers an orange symbol on the Replication Status window as displayed in the attached exhibit.
Click the Exhibit button to view the vDisk Replication Status window.
What does the orange symbol represent on the Replication Status window?

  • A. Replication completed successfully.
  • B. The replicated version is in test mode and CANNOT be replicated.
  • C. The master version was deleted and is no longer available for replication.
  • D. The provisioning server has no access to one of the replicated version vDisks.


Answer : D
